Products > Dump Truck > Semi Trailer Dump Outlet > KB-TB-CK
KB-TB-CK
Semi Trailer Dump Outlet
Structure type
KB-TB-CK
Vehicle model
HCL9402ZZXP
Cargo box specifications
9200*2500*1750
Applicable Working Conditions
  • Characteristic
  • Parameter
  • Case
Intelligent: Intelligent assistance, safe and reliable

♦ Alert: The alignment system of the main trailer, the roll risk can be predicted in advance;

♦ Sensitive: Intelligent driving assistance system, avoiding the risk of blind spots and making it safer;

♦ Intelligence: Locking device of self-opening side door;


Powerful: Strong structure, good craftsmanship, sturdy and durable

♦ Powerful body: Keel frame+ stamping forming, lifting can be made without deformation;

♦ Powerful craftsmanship: Three times of adjustment and three times of positioning, three times of fine adjustment of the braking system + three times of fine adjustments of axle positioning, the guarantee is made with the ingenious craftsmanship ;

♦ Powerful stability: Sunhunk Tianma walking system is more stable and reliable;

♦ Powerful materials: Super wear-resistant steel, super high-strength steel, with an excellent quality;

Speed: Lifting steadily and unloading fast

♦ Fast lifting: “X” power hydraulic system is faster, more stable and more synchronous;

♦ Fast unloading: BFS600 stainless steel bottom plate is adopted for a faster unloading;

♦ Fast service: Service system of Fast, Satisfied and Whole-hearted Service by Sunhunk Tianma;


Light: Light weight and no deformation

♦ Light structure: 2 longitudinal beams + high-strength steel for the whole vehicle, resistant to torsion and deformation;

♦ Light hydraulic system: “X” power hydraulic system, lighter;

♦ Light accessories: Aluminum alloy protection and toolbox structure;

Product Parameters
Key Parameter
Structure type
Vehicle model
Cargo box specifications
Outline size
Material specifications
Type of plate
Hydraulic cylinder
Number of axes
Axle load
Total mass
Conduct oneself with dignity
Tire specifications
Number of tires
Spare tire rack
Working conditions
Used for the road
Transport medium
Auxiliary equipment
Parameter Value
KB-TB-CK
HCL9402ZZXP
9200*2500*1750
10220×2700×3800
7*5*5
K450*K450*K450
5-202*6700
3
10TON
31000KG
12200KG
12.00R20 with inner tube (18 layers)
13
2
Transportation of gravel residue
Hard road surface
Sand, gravel, tar sand
Intelligent fleet management system、Centralised lubrication system
